ATX® Multi Pull Smith Rack

ATX® Multi Pull Smith Rack - multi-gym

The ^ATX® Multi Pull Smith Rack MPHR-780 - 2.0 is an incredible power station! A heavy-duty half rack, professional multi-press, heavy-duty lat pulldowns, and numerous accessories enable an extremely comprehensive and professional range of exercises.

Complete station of superlatives!

• Half Rack with J-Hooks & Spotters
• With linear multi-press

• Lat and rowing station with foot and leg support
• incl. 2 x 110 kg plug-in weights
• With 6 different pulling points
• Pivoting roller boom arms
• With integrated pull-up device
• With integrated deadlift front shelf
• incl. 8 weight plate holders

Six pull points with swivel arms enable multifunctional pulling variations. All six pull points are connected to the two 110 kg plug-in weights with a 2:1 ratio. The two centrally positioned pull pulls can be used alternately and synchronously using the included pull connector. This allows for a variety of single-arm, alternating, or synchronous pulling variations. The coupling allows for professional performance of heavy pulling exercises such as lat pulldowns or seated rowing. The included leg rest and telescopic footrest ensure secure support. The swivel arms attached to the front upright tubes are adjustable in height and width, allowing for both narrow and extra-wide pulling variations (cable crossover).

All relevant barbell exercises can be performed on the free weight rack or the linear multi-press . J-hooks and spotters are included. Furthermore, an additional deadlift barbell rack and a pull-up device are integrated.

The solid, stable construction is absolutely torsion-free, heavy-duty, and of first-class workmanship. Its functionality is outstanding, and adjustments and handling are simple and intuitive.

Heavy, stable construction

• Powerful design
• Made of 70 x 70 x 3 mm thick square steel tube
• Absolutely stable and torsion-free construction
• Front tubes made of stainless steel with lasered system hole pattern
• High dead weight - 645 kg, extremely stable - device does not need to be anchored to the ground
• Heavy-duty - over 1,000 kg frame load
• With rubberized feet - floor-protecting and non-slip
• Abrasion-resistant powder coating
• ATX logo plate in honeycomb design with stainless steel back panel
• With studio approval

incl. J-cups

• made of 10 mm thick steel strip
• with thick all-round protection / rubber protectors - to protect the barbell and to minimize noise
• With internal plastic protectors - to protect the frame / paintwork
• Heavy-duty - up to 500 kg

Incl. spotter arms/emergency trays

• With long projection - 625 mm
• With thick protective pad - to protect the barbell and minimize noise
• Super stable U-frame made of 8 mm thick steel strip
• U-shaped frame with internal plastic protectors - to protect the frame / paintwork
• Heavy-duty - up to 400 kg


With professional multi-press

• silky smooth running characteristics - thanks to 4-fold linear ball bearings
• Minimal bending/twisting thanks to hard chrome-plated steel shafts Ø 30 mm
• Barbell bar made of solid steel Ø 30 mm, knurled and marked for a good grip, black chrome-plated with individually adjustable safety locks with spring buffers
• Weight plate holders Ø 50 mm x 300 mm
• heavy-duty - up to 200 kg
• Guide shafts + weight plate holders in hard chrome plating
• Barbell bar in black chrome - knurled for a good grip, with grip width marking

With 2 x 110 kg plug-in weights

• First-class running characteristics
• Ball-bearing aluminum rope pulleys
• Weight gradation 22 x 5 kg each
• Translation 2:1
• Stretch-free steel cable with protective sheath
• Six different train starting points
  2 x 2 alternating pull points top and bottom + 2 x lateral duplex boom arms
• Incl. leg support cushion roll: removable, easy and quick to adjust individually in height, for secure fixation during lat pulldown
• Incl. telescopic footrest: for secure fixation and maximum range of motion when rowing while seated
• incl. weight plate storage: 8 weight plate holders 50 mm - chrome-plated
• incl. 2 one-hand handles + snap hook

Functional and well thought out down to the last detail

• With all-round system perforation in a fine 50 mm hole pattern
  for attaching additional options and accessories
• Front tubes in high-quality stainless steel
• With lasered numerical scale for precise and fast
  Reproduce the setting heights of J-hooks, roller arms and spotters
• With additional deadlift front rack with dumbbell protection pad
  + optimal loading height for internationally standardized weight plates
• With pivoting roller boom arms
  + Individually adjustable in height and pull range
  + With stainless steel setting scale
  + Swivel range 170°
  + Allows narrow and extra wide cable adjustments (Cable-Cross-Over)

Modular expandable

• The device can be expanded with further first-class ATX ^® options

A rack in proven ATX ^® quality

• German Engineering
• First-class workmanship and function
• Durable and valuable
• With studio approval

Scope of delivery

1 x ATX ^® Multi Pull Smith Half Rack - complete station
including 2 one-hand handles and snap hook

Item number: MS-ATX-MPHR-780

Notice

Delivered disassembled, including assembly instructions - easy assembly.
Delivery subject to prior telephone notification.
